Automotive-Grade High-Voltage LDO
500mA，40V LDO

• Compliant with AEC-Q100 Grade 1 standards for automotive applications

• Internal junction temperature: -40°C to +150°C

• Operating voltage range: 4.3V to 40V

• Output voltage range:

        • Adjustable output: 1.2V to 18V

        • Fixed output: 3.3V and 5V

• Maximum output current: 500mA

• Low quiescent current:

        • Typically 17 µA at light loads

        • Typically 3 µA when disabled

• Features Power Good status indication with programmable delay period

• Package types:

        • 5-pin TO-252 package

        • 8-pin ESOP-8 package with thermal pad

Applications

• Reconfigurable Instrument Clusters

• Body Control Modules (BCM)

• Always-on battery-connected applications: Automotive Gateways, Remote Keyless Entry (RKE)
