Automotive High-Voltage LDO: IM6L4x20 & IM6L4x50

Immorta's IM6L4x20 and IM6L4x50 series are high-efficiency, reliable automotive-grade integrated voltage regulators (LDO). As an ideal automotive power-management solution, Immorta's LDO supports input voltage up to 40 V, connecting directly to the automotive battery and meeting stringent automotive application requirements. Its low-power design and wide current-load range (0–500 mA) improve power-management reliability while effectively reducing energy consumption. This means whether during vehicle start-up or long-term operation, Immorta's LDO provides stable, long-lasting power supply, delivering a high-reliability, low-energy-consumption experience — an ideal choice for modern automotive power-management needs.

Main Features

• AEC-Q100 automotive-grade certified
• Operating junction temperature: -40℃ to +150℃
• Input 4.3 V to 40 V, adapts to various automotive power environments
• Low power: typical quiescent current only 13µA at light load
• Output 200 mA ~ 500 mA, meets different current needs
• ±2% output-voltage accuracy for stable supply
• Over-current, short-circuit, and over-temperature protection for safe operation
• High noise rejection: PSRR > 70 dB @ 100 Hz
• Multiple packages: SOT223-4L, WSON6, ESOP-8, for space-constrained applications

Highlights

• Supports up to 40 V input and low quiescent current, greatly reducing power consumption
• AEC-Q100 Grade 1 certified, ensuring stability in harsh environments
• Efficient energy management
• Strong reliability
• Multiple protection functions improve system safety, suitable for high-safety automotive applications
• Multiple packages and adjustable voltage, meeting diverse application needs
• Flexible application scenarios
• Multiple protection mechanisms

Applications

200 mA, 40 V LDO: IM6L4x20

AEC-Q100 Compliant

• AEC-Q100 Grade 1 for automotive applications
• Operating junction temperature: -40℃ to 150℃
• Wide input voltage range: 4.3 V to 40 V; 5 V or 3.3 V output selectable
• Rated output current 200 mA
• Output voltage accuracy ±2%
• Quiescent current 13µA (typical)
• Over-current and short-circuit protection
• Over-temperature protection
• High noise rejection, PSRR > 70 dB @ 100 Hz

• Fewer external components for excellent transient response
• Packages: SOT223-4L, SOT23-5L, SOT89-5L, WSON6, ESOP-8

Package Form

Typical Application

500 mA, 40 V LDO: IM6L4x50

AEC-Q100 Compliant

• AEC-Q100 Grade 1 for automotive applications
• Operating junction temperature: -40℃ to 150℃
• Operating voltage range: 4.3 V to 40 V
• Output voltage range:
• Adjustable output: 1.2 V to 18 V
• Fixed output: 3.3 V and 5 V
• Rated output current: 500 mA
• Low quiescent current:
• Typical 17µA at light load
• Typical 3µA when disabled
• Power-Good indication with programmable delay

• Package types:
• 5-pin TO-252
• 8-pin ESOP-8 with thermal pad

Package Form

Typical Application

IM6L4x20 Series:

Product Models

IM6L4x50 Series:
